Type: Reconnaissance fighter
Crew: Two
Origin: Bayerische Flegzeugwerke

---

Powerplant:

• Model: Daimler-Benz DB 601N
• Type: Liquid-cooled, inverted V12
• Number: Two
• Horsepower: 1,200 hp

Fluids:

• Fuel Capacity: 279 Imperial Gallons in wing cells
• Oil Capacity: 7.7 Imperial Gallons per engine

---

Dimensions:

• Wing span: 53 ft. 4¾ in. (16.25m)
• Length: 39 ft. 8½ in. (12.1m)
• Height: 11 ft. 6 in. (3.5m)
• Wing Surface Area: 413 Sq. ft.

---

Weights:

• Empty: 4,500kg (9,920 lbs.)
• Loaded: 7,000kg (15,430 lbs.)

---

Performance:

• Maximum Speed: 349 mph (562 kph) at 22,965 ft (7,000m)
• Range: 528 mls (850 km) at 304 mph (490kph) at 16,400 ft. (5,000m)
• Initial climb: to 5,500m (18,045 ft.) in 8 minutes
• Service Ceiling: 32,800 ft. (10,000m)

---

Armament:

• Rear Gun in flexible mounting in rear cockpit
• One 7.9mm MG 15 Machine Gun with 750 rounds.
• Racks for two 250kg bombs.

---

Optics/Photographic Equipment:

• Serial camera Rb 50/30

Sources:
Gunston, Bill - The Encyclodepia of the Worlds Combat aircraft, 1976, Chartwell Books, Inc., New York
Brown, Eric, Captain - Wings of the Luftwaffe, 1979, Airlife Publishing Ltd., Shrewsbury
Gunston, Bill & Wood, Tony - Hitler's Luftwaffe, 1977, Salamander Books Ltd., London
Donald, David - The Complete Encyclopedia Of World Aircraft, 1997, Brown Packaging Books Ltd., London
Wikipedia - BF 110
