Type: Attack
Origin: Beech
Crew: Three
Model: Beech Model 28
First Flight: 1945
Final Delivery: N/A
Aircraft Produced: 2
Engine:
   Model: Wright R-3350-42 Cyclone
   Type: Radial piston engine
   Number: Two       Horsepower: 2,300 hp
Dimensions:
   Wing span: 67 ft. 4 in. (20.52m)
   Length: 51 ft. 9 in. (15.77m)
   Height: N/A
   Wing Surface Area: N/A
   Weights:
   Empty: N/A
   Loaded: 35,264 lb. (15,995 kg)

Performance:
   Maximum Speed: 376 mph (605 kph)
   Initial Climb: N/A
   Service Ceiling: N/A
   Range: N/A
Armament:
75mm Cannon

Payload: N/A
Avionics: N/A

Some pop-up blockers may prevent this photo from appearing.   Some pop-up blockers may prevent this photo from appearing.   Some pop-up blockers may prevent this photo from appearing.   Some pop-up blockers may prevent this photo from appearing.   Some pop-up blockers may prevent this photo from appearing.


Sources:
The Complete Encyclodepia of World Aircraft, 1997, Barnes & Nobles Books, ISBN: 0 7607 0592 5
