BRISTOL BRIGAND


Type: Multi-Role Attack Bomber
Crew: Three
Origin: Bristol
Models: Brigand B.1 to T.5
First Flight: December 4, 1944
Service Delivery:
– To Coastal Command: June 1946
– Brigand B.1: December 1948
Final Delivery (T. 4): 1950
Withdrawn from service (T. 5): 1958
Number Produced: 147

Engine:
  Model: Bristol Centaurus 57
  Type: 18 Cylinder Sleeve-valve radial
  Number: Two    Horsepower: 2,810 hp*
         *With Methanol/Water Injection

Dimensions:
Wing span: 72 ft. 4 in. (21.9m)
Length: 46 ft. 5 in. (14.1m)
Height: 17 ft. 6 in. (5.33m)
Wing Surface Area: N/A
  Weights:
Empty: 25,598 lbs. (11,612 kg)
Loaded: 39,000 lbs. (17,690 kg)

Performance:
Maximum Speed: 360 mph (575 km/h)
Initial climb: 1,500 ft./min. (456 m/min)
Service Ceiling: 26,000 ft. (7925 m)
Range:
   Internal Fuel: 1,980 Miles (3168 km)
   With Drop Tanks: 2,800 Miles (4506 km)

Armament:
Four 20mm Hispano Mk. V cannon fixed in forward fuselage.

Payload:
Centerline racks for torpeods or up to 2,000 lb.
(907 kg.) of ordnance.

Underwing racks for 16 rocket projectiles or other ordnance.

Overview:
The Brigand was developed by the Bristol Aeroplane Company as a anti-shipping/ground attack/dive bomber attack aircraft to replace the Beaufighter. The Brigand was the Royal Air Forces first purpose built multi-role strike aircraft as well as its last piston engined bomber. Although only a total of 147 were built, they continued to serve the Royal Air Force after World War II in Malaya during the Malayan Emergency and in Kenya. They were eventually replaced by the English Electric Canberra jet bomber except in Malaya where they were replaced with the de Havilland Hornet.

Design/Development:
In 1942 the British Air Ministry released specification H.7/42, calling for a replacement for the Bristol Beaufighter. This replacement was to be faster than the Beaufighter and capable of long-range torpedo attacks and anti-shipping strikes. The design team at Bristol Aeroplane Company, led by Leslie J. Frise, came up with the Bristol Type 164.

The Brigand design used the wings, undercarriage and tail assemblies from the Bristol Buckingham mated to a new fuselage with a oval cross section. The three person crew was grouped together in the cockpit and consisted of the pilot, a navigator/bombadier, and a gunner who also served as the radio-operator. As the Type 164 entered production the specifications changed and the role of the Brigand changed to bomber. However, the first 11 Brigands produced were completed as torpedo bombers. These aircraft were assigned to RAF Coastal Command from 1946-1947 before eventually being converted to the standard bomber configuration.

Service History:
45 Squadron, based at RAF Station Tengah in Singapore, was the first unit to convert to the Brigand. The first Brigand was flown from RAF St. Athan to Singapore in November 1949, a trip that took 16 days to complete. After initial acceptance test flights were completed, this single Brigand commenced combat operations in support of British forces fighting against the Communist Guerrillas insurgents in Malaya. On December 19, 1949 the Brigand was flown on its first combat mission by Flight Lieutenant Dalton Golding along with radio/radar operator Peter Weston and were joined by four Beaufighters of No. 45 Squadron. The mission was to strike at targets in the jungle near Kluang, Malaya. The mission was successful and soon 45 Squadron completed the transition to the Brigand as more aircraft became available.

After the transition, Brigands of 45 Squadron were routinely involved in strikes against Communist insurgent targets around Malaya, eventually being joined by 84 Squadron. These missions involved direct strikes as well as close support missions for ground forces. The Brigands also provided air cover for convoys facing the possibility of ambush.

Some pop-up blockers may prevent this photo from appearing.

It wasn't long before problems with the Brigand began to appear. One of the first problems involved the main undercarriage failing to lower. This problem was discovered to be caused by a failure of the rubber seals in the hydraulic jacks of the landing gear. The rubber seals gradually degraded due to exposure to the hot and humid environment in Malaya, an environment that the seals was not necessarily designed for. This problem was soon resolved but was by no means the only problem experienced, or even the most serious one. The losses of several aircraft during strafing runs and several more being damage led to the discovery of a deadly problem. The long cannon blast tubes that ran beneath the cockpit seemed to have the tendency of trapping propellant gases when the four cannons were fired. This gas would occasionally ignite when the aircraft used high explosive rounds, the resulting explosion would damage hydraulic lines and fire would severly damage the aircraft or cause it to crash . The solution for this was to limit the ammunition load and restrict the cannons to using only solid rounds.

Another inconvenient problem was the failure of the propeller assembly causing one propeller blade to depart the aircraft. This would quickly lead to complete propeller failure and the resulting unbalanced engine would inevitably tear itself off the wing, often leading to the aircraft crashing. The environment was again the culprit, this time the humidity lead to corrosion of the propeller locking rings. A revision to the maintenance program helped to alleviate this issue.

Some pop-up blockers may prevent this photo from appearing.

At one point, the commanders of the units that operated the type began to have doubts over the wisdom of continueing operations. Eventually it was decided that the Brigand would remain in service as long as strict maintenance would be carried out, minimizing the threat of failure.

Unfortunately, an additional issue presented itself. The Brigands air brakes, used to slow the aircraft during a dive, were actuated by leather bellows. Once again the environment reared its relentless head and degrading the leather of the bellows. This would cause the air brakes to fail during deployment, leading to wing failure due to excessive airspeed, either in the dive or when the aircraft pulled out. The solution to this problem was to wire the air brakes shut, though this degraded the Brigand's performance when dive bombing.

In January 1952, No. 45 Squadron gave up it's Brigands and transitioned to de Havilland Hornets leaving 84 Squadron as the sole operator in the region. In February 1953, 84 Squadron disbanded, ending the squadron use of the Brigand in the region. The remaining Brigands were grounded soon thereafter and withdrawn from service. The Brigand was also used by No 8 squadron over Aden from 1950-1952.

When things went as they were designed to do the Brigand was a good aircraft and the pilots that flew the type considered it a pleasant aircraft to fly.


Variants:
– Brigand I or TF.1 - initial aircraft built as torpedo bombers, later rebuilt as bombers, B.1
– Brigand Met 3 - meteorological reconnaissance aircraft, 16 built.
– Brigand T.4 - trainer version, used to train airborne interception radar operators. 9 built
– Brigand T.5 - improved training version, used to train airborne interception radar operators.

Users/Operators:

Pakistan
– Royal Pakistan Air Force

United Kingdom
– Royal Air Force
— No. 8 Squadron
— No. 45 Squadron
— No. 84 Squadron
— No. 1301 (Met) Flight
— No. 228 Operational Conversion Unit
— No. 238 Operational Conversion Unit


Sources:
Gunston, Bill - The Encyclodepia of the Worlds Combat aircraft, 1976, Chartwell Books, Inc., New York
Green, William - War Planes Of The Second World War - Fighters - Vol. 2, 1961, Hanover House, NY
