Type: Carrier based fighter-bomber Origin: Ryan Crew/Seats: One Model: FR-1 & XFR2-1 First Flight: First Prototype: June 25, 1944 XFR2-1: November 1946 Service Delivery: March 1945 Removal from Service: 1947 Powerplant(s): FR-1: Model: Wright R-1820-72W Cyclone Type: Radial piston engine Number: One Horsepower: 1,425 hp Model: General Electric J31 Type: Turbojet Number: One Thrust: 1,600 lb XFR2-1: Model: General Electric XT-31-GE-2 Type: Turboprop Number: One Horsepower: N/A Model: General Electric J31 Type: Turbojet Number: One Thrust: 1,600 lb |
Dimensions: Wing span: 40 ft. 0 in. (12.19m) Length: 32 ft. 4 in. (9.86m) Height: 13 ft. 7¼ (4.15m) Wing Surface Area: 275 Sq. Ft. (25.55m²) Weights: Empty: 7,915 lb. (3590 kg) Loaded: 10,595 lb. (4806 kg) Performance: Maximum Speed: 426 mph (686 kph) at 18,100 ft. Cruising Speed: N/A Initial Climb: N/A Service Ceiling: 43,100 ft. (13,135m) Range: 1,30 miles (1658m) Armament: N/A Payload: N/A |
The Complete Encyclodepia of World Aircraft, 1997, Barnes & Nobles Books, ISBN: 0 7607 0592 5
