Messerschmitt Bf 109 F-3

Bf 109 F-4 (Sorry, closest I could come to an F-3)


Type: Single-seat fighter
Origin: Bayerische Flegzeugwerke

Powerplant:
One Daimler-Benz 601E Liquid Cooled Inverted V12
Horsepower: 1,300hp

Fuel:
Capacity: N/A
Type: N/A

Dimensions:
Wing span: 32 ft. 6.5 in.
Length: 29 ft. 0.5 in.
Height: 8 ft. 6 in.
Wing Surface Area: N/A

Weights:
Empty: 4,330 lb.
Maximum, Loaded: 6,054 lb.

Performance:
Maximum Speed: 390 mph at 22,000 ft.
Maximum Climb: 3,320 feet per minute

Range: 440 Miles

Service Ceiling: 37,000 ft.

Armament:
One 15mm MG 151 mounted between cylinder heads and firing through the propeller hub with 200 rounds
And
Two 7.9mm MG 17 mounted above engine with 500 rounds per gun

Avionics:
N/A
