 Type:
Communications, Liaso,
Ambulance, Utility

Origin: Bayerische Flugzeugwerke (BFW)

Capacity: 4

Models: A, B, C proposed but not built
Engine:
Argus As 10C inverted V8 air cooled
Horsepower: 240 hp
Propeller Unit: N/A
Diameter: N/A

Fuel/Fluids:
Fuel Capacity: N/A
Type: N/A

Lubricant Capacity: N/A
Type: N/A

Hydraulic Fluid Capacity: N/A
Type: N/A

Dimensions:
Wing span: 10.62m (24 ft. 10 in.)
Wing Surface Area: 176.53 sq. ft.
Length: 8.29m (27 ft. 2.5 in.)
Height: 2.30m (7 ft. 6.5 in.)
Stabilizer Span: N/A
Wheel Track: N/A

 Weights:
Empty: 880kg (1,940 lbs.)
Loaded: 1,352kg (2,981 lbs.)

Performance:
Maximum Speed: 196 mph (315 kph)

Range (Fully Loaded): 1,400km (870 miles)

Initial Climb: N/A
Endurance: N/A
Service Ceiling: 5,000m (16,405 ft.)

Armament:
None

Avionics:
None

Image 1 - Same aircraft as above. On ground.
Image 2 - A captured Bf 108. (FE-4?10)
Image 3 - A restored Bf 108.
 Image 4 - Cockpit of the restored plane.
Image 5 - Pre-war picture of German Embassy to England's aircraft.
Back To Trainers Menus
Back To Main Menus
Sources:
Gunston, Bill & Wood, Tony - Hitler's Luftwaffe, 1977, Salamander Books Ltd., London
