Type: Carrier based dive bomber Origin: Yokosuka Crew: One Allied Code Name: Judy Models: D4Y1 to D4Y4 First Flight: December 1940 Service Delivery: Autumn, 1942 Final Delivery: N/A Production: 2,038 Powerplant: D4Y1 Prototype: Model: Daimler-Benz DB600G Type: 12-Cylinder liquid-cooled inverted-vee Number: One Horsepower: 980 hp D4Y1: Model: Aichi Atsuta AEIA 32* Type: 12-Cylinder liquid-cooled inverted-vee Number: One Horsepower: 1,200 hp *Licensed built Daimler-Benz DB601A D4Y2: Model: Aichi Atsuta AEIP 32* Type: 12-Cylinder liquid-cooled inverted-vee Number: One Horsepower: 1,400 hp *Licensed built Daimler-Benz DB601A D4Y3: Model: Mitsubishi MK8P Kinsei Type: radial Number: One Horsepower: 1,560 hp |
Dimensions: Wing Span: 37 ft. 8¾ in. (11.50m) Length: 33 ft. 6 in. (10.22m) Height: 12 ft. 3 in. (3.74m) Wing Area: 254.04 sq. ft. (23.60m²) Weights: Empty: 5,379 lb (2440 kg) Loaded: 9,370 lb (4250 kg) Performance: Max. Speed: 342 mph (550 kph) Service Ceiling: 35,105 ft. (10,700m) Range: 910 miles (1465 km) Armament: D2Y2 (Typical) Two 7.7mm machine guns firing forward. One 7.92mm machine gun firing to the rear. D2Y2a Two 7.7mm machine guns firing forward. One 13mm machine gun firing to the rear. D2Y2-S One 20mm cannon firing obliquely forward. Payload: D2Y2 Up to 1,765 lb. (800 kg) of bombs carried externally. |
Sources:
The Complete Encyclopedia of World Aircraft
, 1997, Barnes & Nobles Books, ISBN: 0 7607 0592 5WARBIRDS RESOURCE GROUP > IJARC > BOMBERS > PREVIOUS PAGE
