Type: Single Set Jet fighter (later trainer,
Photo Reconnaissance, Nightfighter, drone and target tug variants.) Origin: Gloster (later Hawker Siddeley) Models: See variant list. First Flight: Prototype: March 5, 1943 NF.11: May 31, 1950 Squadron Delivery: (F.1) July 12, 1944 Final Delivery: (T.7) July 1954 Number Produced: 3,947 Engine: Meteor I Model: Rolls-Royce Welland Type: Centrifugal Turbojet Number: Two Thrust: 1,700 lb. Meteor F.3 Model: Rolls-Royce Derwent 1 Type: Centrifugal Turbojet Number: Two Thrust: 2,000 lb. Meteor Mk. 4 Model: Rolls-Royce Derwent 5 Type: Centrifugal Turbojet Number: Two Thrust: 3,500 lb. Meteor F.8 Model: Rolls-Royce Derwent 8 Type: Centrifugal Turbojet Number: Two Thrust: 3,600 lb. Dimensions: Wing span: Mk. 4, 7, 8, 9 and derivatives: 37 ft. 2 in. (11.3m) Mk. 1-3, 10-14: 43 ft. (13.1m) Length: Mk. 1-4: 41 ft. 4 in. (12.6m) Mk. 7, 9: 43 ft. 6 in. (13.25m) Mk. 8: 44 ft. 7 in. (13.59m) Mk. 10: 44 ft. 3 in. Mk. 11-13: 48 ft. 6 in. (14.78m) Mk. 14: 49 ft. 11.5 in. (15.23m) Height: Mk. 1-7, 10: 13 ft. (3.96m) Mk. 8, 9, 11-14: 13 ft. 10 in. (4.22m) Wing Surface Area: N/A Weights: Empty: Mk. 1: 8,140 lb. (3693 kg) Mk. 4: 9,980 lb. (4526 kg) Mk. 7: 10,540 lb. (4780 kg) Mk. 8: 10,626 lb. (4820 kg) Mk. 9: 10,790 lb. (4895 kg) Mk. 11-14: about 11,900 lb. (5400 kg) Loaded: Mk. 1: 13,800 lb. (6260 kg) Mk. 4: 15,175 lb. (6885 kg) Mk. 7: 17,600 lb. (7984 kg) Mk. 8: 19,100 lb. (8664 kg) Mk. 9, 10: 15,660 lb. and 15,330 lb. Mk. 11: 22,000 lb. (9979 kg) Mk. 12-14: about 20,500 lb. (9300 kg) |
Performance: Maximum Speed: Mk. 1: 410 mph (660 km/h) Mk. 4, 8, 9: 585-595 mph (940-958 km/h) Mk. 7, 10-14: 579-585 mph (931-940 km/h) Initial Climb: Mk. 1: 2,155 ft/min (657 m/min) Mk. 4-10: 7,000-7,600 ft/min (2130-2315 m/min) Mk. 11-14: 6,000 ft/min (1830 m/min) Service Ceiling: Typical: 40,000-44,000 ft. (12,192-13,410m) F.8: 50,000 ft. (15,240m) Range (Internal Fuel, Typical): About 1,000 miles at altitude. Armament: Mk. 1-4, 8, 9: Four 20mm Hispano Cannon on sides of nose. Mk. 11-14: Four 20mm Hispano Cannon in outer wings. Other Marks: Normally none. Payload: Most Meteors had the capability of being modified to carry two 1,000 lb. bombs, eight rockets or various other offensive stores. However, few Meteors actually revieved these modifications except for some F.8 fighters in non-British service. Variants List: Meteor I: First production batch of fighters delivered to Squadron 616 on July 12, 1944. F.3: First major production version. Included extra tankage, sliding canopy and on the last 15 longer nacelles. Mark 4: More powerful engines, larger nacelles and clipped wing tips. In 1945 set speed record of 606 mph, increased to 616 mph the following year. T.7: Tandem seat trainer with canopy hinged to right. PR.10: Unarmed reconnaissance. F.8: fighter variant introducing a redesigned tail, more powerful engines, greater load, improved cockpit, and a Martin-Baker ejection seat. Later 8's had enlarged engine inlets, spring-tab ailerons, and an improved canopy. The F.8 was the most numerous variant built and was widely exported after the war. NF.11-14: Tandem seat nightfighters with AI. 10 or APS-57 (U.S. Built) radar. Armstong Whitworth built these variants, producing 547 aircraft. Major Conversions: NF(T).14: Navigation Trainer. U.15, U.16 and U.21: unmanned, remotely piloted aircraft. TT.20: target-tug. |
